| • Connector
- Input : HDMI A type (female)
- Output : D-sub 15pin (female), Mini audio jack (female)
• Pixel Clock : 165MHz (single link)
• Supporting Resolution :
- WUXGA (1920 x 1200) @ 60Hz
- 1080p (1920 x 1080) @ 60Hz
• Audio : Stereo / Mono
• Power Consumption : 2.97W (max)
• Power Supply : 100 ~ 240V with DC 5V, 2A
• Dimension : 77W x 46D x 21H (mm) / Weight 85g
• Operating Temperature range: 0°C ~ 50°C
• Storage Temperature range: -20°C ~ 70°C |
